Ts008p Hank To Cone Winding Machine

In order to cater the varied demand of the customers we are occupied in manufacturing exporting and supplying a superior quality range of TS008P Hank to cone Winding Machine in Xinghua Jiangsu Sheng China. These machines are manufactured at our state-of-the-art manufacturing facility by making use of quality raw material and employing cutting edge technology. Further these are tested on several parameters to ensure their durable and defect free nature and flawlessness.

Feature:
1. Drive: every spindle per motor
2. Winding speed: 300-600 M/min
3. Has function of auto stop when yarn break.
4. Package Diaa 250mm; Take-up Traverse: 150mm;
5. Each spindle with length counter;
6. Advanced control panel;

Technical parametersi
Bobbin type:6"(170mm)
LayoutDouble-side can be 12-96 spindles
Power SupplyThree phases 380V 50/60HZ
DrivingEvery spindle per motor
Power Consumption0.09KW/spindle
Take-up packageTube Bobbin (0A ) / Cone 4A 20 5A 57 9A 15
Yarn tension and waxing deviceEvery spindle has a yarn tension and waxing device
Auto Stop DeviceEach spindle install auto stop device
Electronic Anti-StackInverter control
Cleaner deviceEvery spindle has a Mechanical Knife yarn cleaner
DimensionsL 13700 x W 1150 x H 1500 mm
