Batch Off Cooler

This batch off cooler machine is the downstream auxiliary machine to the internal mixer or the dispersion mixer.Make rubber sheet pressed from mixing mill coolingreducing cooling time and space to cool sheet to improve capacity of whole line.
It works with the double conical-screw extruder sheeter and is designed to perform continuous operation of rubber slab conveyingcoating separantair coolingdryingcutting and wig-wag stacking.
Parameter(adjustable)
Specification
XKP-600 XKP-800
Width of pegged plastic rod(mm)
720 920
Maximum length of suspension film(mm)
1500 1500
The largest plastic peg volume(kg)
1300 1500
Effective width of pegged plastic rod(mm)
600 800
Film thickness(mm)
6-12 6-12
Film initial temperature(A C)
90-120 90-120
Pegged plastic temperature(A C)
60-70 60-70
Drop temperature
Release agent temperature
20-40 20-40
Total motor power(approx)(kw)
13 13
Gas source pressure(Mpa)
0.6-0.8 0.6-0.8
Dimensions(m)
11A 2A 3.3 11A 2A 3.3
Weight(approx)(Kg)
7000 7000
