Cnc Gantry Milling Machine Dosage Form: Liquid

We are trading and supplying a CNC Gantry Milling Machine in Ahmedabad Gujarat India.

Machine type : CNC Gantry Milling Machine
Make : Waldrich Coburg
Type : 6000 x 2300
Newin : 1994
Control : Siemense 880M
Location : Europe
Country of origin : Germany
Term of delivery : at Immediate
Quotation : Free loaded; Container/Truck
Price

Technical details
Table size (2x table) : 9000 x 2500 mm
X-travel - Longitudinal : 10000 mm
y-travel a Cross Travel : 4000 mm
Table size Each : 4000 x 2500 mm
Z-travel (Spindle head stock) : 2500 mm
Distance between column : 3000 mm
Max Dis. between spindle - Table : 2500 mm
Table load capacity/table : 80 tone
Turn table to use as VTL : 2500 mm
Milling spindle power : 95 kW
Milling spinlde speed : 2-2500 rpm

Tool taper ISO : ISO 60
Angular head tool type : SK50
weight of the machine ca.
Dimensions of the machine ca. : 232 x 10 x 82 m

Hydrostatic Guide ways in axis
Hydraulic counter balancing for cross rail & spindle head
Ball screws in all axis
Feed back with liner scales Heidenhain
Motorised adjustments for control panel
Coolant through spindle & external
With Chip conveyor
Turn Table to use as VTL a as C-axis

Turn table diameter 2500 mm
Turn table speed 120 rpm
Turn table cutting force 50000 N
Turn table power 75 kW
Turn table position accuracy +/- 3 sec

Double table :

Table I X- axis 4500 mm
Table II X-axis 4500 mm
Table clubbed together X-axis 10000 mm
Table load capacity 20000 kg/m
