Gravity Casting Machines For Ornamental Aluminum Cast

We are leading manufacturer supplier and exporter of Gravity Casting Machines For Ornamental Aluminum Cast in Quanzhou Fujian China. This machine is used in casting not only aluminum but also zinc and some other metals and the main point they can't used in brass and copper. If you want cast brass or copper please choose our products JD-AB500 or JD-AB400


Aluminum gravity die casting
Item No.: JD-600 Tilt Gravity Die Casting Machine for aluminium.

Technical parameters:
1.Maximum size of mould frame:(600*500*600)mm
2.Maximum clamping force: 45KN
3.Maximum opening mould :38KN
4.Minimum shut height:350mm
5.Maximum stroke of dynamic mold:350mm
6.Top core oil cylinder output:38KN
7.The angle of working platform rotation:0A - 90A
8.The speed of working platform rotation:8A /Sa Va 4A /S
9.Hydraulic station power:3.75kw
10.Hydraulic system pressure rating:6.5Mpa
11.Hydraulic system working pressure:5.5-10Mpa
12.Control:manualautomatic
13.Plunger pump (Taiwan imports):25cc/rev
14.Human-computer conversation:Siemens touch screen
15.Net weight of the Equipment :2.6T
16.Maximum dimension of the equipment (LXWXH):2500mm*1500mm*1600mm
JD600Aluminum alloy casting machine Technical parameters
Maximum size of mould frame(600*500*600)mm
Maximum clamping force45KN
Maximum opening mould38KN
Minimum shut height350mm
Maximum stroke of dynamic mold350mm
