Hydrotechnik 3403-15-d5.37s Pressure Sensor Pr150

Hydrotechnik 3403-15-D5.37S Pressure sensor PR150

Product range pressure sensors type HT-PD PR150The latest thinfilm WSG pressure sensor type HT-PD PR150 from Hydrotechnik was developed in order to measure pressures and pressure peaks within an extended temperature band. Its strongest attributes lie in the following areas:AcA Ac ReliabilityAcA Ac RepeatabilityAcA Ac Temperature stabilityAcA Ac Robust industrial designAcA Ac Media compatibilityAcA Ac Resistance to thermal shocks and vibrations

Hydrotechnik pressure sensors HT-PD PR150 4...20mA output
Measuring range(MPa)Measuring range(Bar)4...20mA
-0.1...0MPa-1...0bar3403-30-D5.37
-0.1...0.6MPa-1...6bar3403-32-D5.37
-0.1...1MPa-1...10bar3403-54-D5.37
0...0.6MPa0...6bar3403-28-D5.37
0...1.0MPa0...10bar3403-26-D5.37
0...1.6MPa0...16bar3403-41-D5.37
0...4.0MPa0...40bar3403-31-D5.37
0...6.0MPa0...60bar3403-21-D5.37
0...10.0MPa0...100bar3403-16-D5.37
0...20.0MPa0...200bar3403-10-D5.37
0...25.0MPa0...250bar3403-17-D5.37
0...40.0MPa0...400bar3403-15-D5.37
0...60.0MPa0...600bar3403-18-D5.37
0...100.0MPa0...1000bar3403-29-D5.37
Hydrotechnik pressure sensors HT-PD PR150 0...10VDC output
Measuring range(MPa)Measuring range(Bar)0...10VDC
-0.01...0MPa-0.1...0bar3403-60-D5.39
-0.1...0.2MPa-1...2bar3403-68-D5.39
-0.1...0.6MPa-1...6bar3403-32-D5.39
0...0.02MPa0...0.2bar3403-61-D5.39
0...0.2MPa0...2bar3403-25-D5.39
0...0.6MPa0...6bar3403-28-D5.39
0...1.0MPa0...10bar3403-26-D5.39
0...2.0MPa0...20bar3403-27-D5.39
0...2.5MPa0...25bar3403-40-D5.39
0...4.0MPa0...40bar3403-31-D5.39
0...6.0MPa0...60bar3403-21-D5.39
0...10.0MPa0...100bar3403-16-D5.39
0...20.0MPa0...200bar3403-10-D5.39
0...25.0MPa0...250bar3403-17-D5.39
0...40.0MPa0...400bar3403-15-D5.39
0...60.0MPa0...600bar3403-18-D5.39
0...100.0MPa0...1000bar3403-29-D5.39
