Motorized Gyroscope Apparatus - Stainless Steel Diameter 300 Mm X 12 Mm Thick | Easy To Operate Accurate Measurement Long Service Life

MOTORIZED GYROSCOPE APPARATUS
Manufacturing done in compliance with the set industry norms and guidelines the offered Motorised Gyroscope Apparatus has its quality highly standardized.
The finest raw materials and modern machines applied in its making give the product superior performance and a longer service life. In addition the offered range is marked at the most reasonable rate possible.
We are a prominent firm engaged in offering Motorized Gyroscope Apparatus.
The product is provided with a stainless steel disc mounted on a horizontal shaft.
The variable speed motor of the product is mounted on a trunnion frame having bearings in a yoke frame which freely rotates about its vertical axis.
To maintain a proper balance the apparatus is installed with a weight pan on the other side of the rotor disc which can be moved about three axis.
Scope of Experimentation
Observation of gyroscopic effect of rotating disc
To study the gyroscopic effect of a rotating disc
Experimental justification of the equation T = l w. wp for calculating the gyroscopic couple by observation and measurement of results for independent vibrations in applied couple T and precession wp
Utilities Required
1m x 1m 230 V AC single phase
Bench area
Tachometer to find out RPM of disc
Electric supply
Technical Details
Stop Watch Electronic
Variable speed of standard make
Supplied with Speed Control Unit
Weights: 2 kg 1 kg kg
Stainless Steel
Diameter: 300 mm x 12 mm thick precisely balanced which can be rotated in 3 mutually perpendicular axis
Motor
Accurately marked scale & pointer to measure precession rate
Features:
Easy to operate
Accurate
Longer service life
